Modulift has recently finished the testing of MOD 1100 modular spreader beam, the largest supplied standard beam in the Modulift range with a lifting capacity of 2000 tonnes. Ordered by a Belgian client for Offshore Monopoly installations, the 30-metre-long beam comes complete with DNV GL type approval as standard. Fitted with optional extras including upper shackle supports to protect the synthetic top slings when resting and two 45t tugger points on each end. The Pewag PLDW 45t tugger points were supplied by Prolift UK.
![Drop link testing tensile test rig](https://moveitmagazine.com/wp-content/uploads/2022/11/Drop-link-testing-tensile-test-rig.jpg)
![MOD 1100 2000t Spreader Beam 1](https://moveitmagazine.com/wp-content/uploads/2022/11/MOD-1100-2000t-Spreader-Beam-1.jpg)
The test was carried out in Modulift’s recently upgraded 2200t x 30 metre compression test rig and was third party witnessed by the client and DNV GL. The two drop links were tested in Modulift’s newly built 1500t tensile test rig. The whole operation was successfully executed over three days with individual tests carried out at 19 metre, 20 metre and 30 metre spans.
![MOD1100 2000T Drop Link Testing 1](https://moveitmagazine.com/wp-content/uploads/2022/11/MOD1100-2000T-Drop-Link-Testing-1.jpg)
